PROmesh P10X - Managed switch with IP67 for Industry 4.0

The PROmesh P10X is an Industrial Ethernet/PROFINET managed switch with IP67 protection class and EtherNet/IP compatibility, designed for use in harsh industrial environments.

Product highlights

IP67 certification for protection in demanding environments
Supports various applications such as EtherNet/IP or PROFINET
Data transmission up to 1.0 Gbit/s via M12 X-coded ports
Operation in extended temperature ranges
UL/CSA certification complies with international safety standards

Request quotation

Art. No. 114110210
In stock

The PROmesh P10X is a powerful industrial Ethernet switch and offers a first-class solution for Industry 4.0 applications. Its IP67 certification enables installation without a control cabinet or terminal box. Thanks to its compatibility with various applications (PROFINET, EtherNet IP, Ethernet), it can be flexibly integrated into various industrial networks. The PROmesh P10X meets the requirements of modern industrial applications thanks to its high transmission speeds and a throughput rate of 14.88 Mpps.

The EPLAN macro provided facilitates integration into existing concepts. Integrated diagnostic functions enable continuous monitoring of the network status. UL/CSA certification guarantees compliance with international safety standards. The robust design of the switch ensures reliable operation, even under extreme conditions.

Functions:

Up to 100 Mbps transfer rate via M12 D-coded ports and 1.0 Gbps via M12 X-coded ports
14.88 Mpps throughput rate
Compact design and flexible mounting options
Line diagnostics, EMC monitoring and performance monitoring for comprehensive network monitoring

Start web demo

Ports	8 x 100 Mbit/s M12 2 x 1 Gbit/s M12
PROFINET Standard	CC-B according to V2.4
Monitoring	Line, EMC, 24 V, Temperature, Port Statistics, Network Load
Netload Class	III
Redundancy	MRP, RSTP
Protection Class	IP 67
Dimensions (H x W x D in mm)	284 x 60 x 28
Firewall	x
Routing	x
Mounting Type	Wall Mounting
Backplane	20 Gbit/s
Throughput	14.9 Mpps
Shared Buffer	2 Mbit
Certifications	UL/CSA CE UK CA
